TFT Color Multifunctional Meter Calibration Equipment 560V

Name: TFT Color Multifunctional Meter Calibration Equipment 560V
Brand: GFUVE
Price: 1 USD

China TFT Color Multifunctional Meter Calibration Equipment 560V factory

Brand Name : GFUVE

Model Number : GF312V2

Place of Origin : BEIJING,CHINA

MOQ : 1SET

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 1500SETS/MONTH

Delivery Time : 1-2WEEKS

Packaging Details : CARTON

ACCURACY : 0.05%, 0.1%

POWER SUPPLY : External power, 220V/110V, 50/60Hz

TESTING VOLTAGE : 30-560V

HARMONIC : 2nd-51st

TESTING CURRENT : 0.01-10A

FREQUENCY : 45Hz-65Hz

PULSE CONSTANT : 25000

DISPLAY : 7” TFT color (480×234)

MULTIFUNCTIOAN : EXTRA KEY AND PRINTER

DIMENSION : 245×168×70MM

WEIGHT : 1.8KG

Contact Now

TFT Color Multifunctional Meter Calibration Equipment 560V

High accuracy 0.05%
Screen capture function
Input two pulse signal for master and slave meter synchronously calibration
Large size display screen, direct viewing and convenient
Internal communication port for PC control
Multiple power supply for different testing occasion
Large capacity storage device for mass memory

TECHNICAL PARAMETERS

Electrical parameters
Accuracy class	0.05%, 0.1%
Power Supply	External power, 220V/110V, 50/60Hz Phase voltage supply 45-450V, 50/60Hz Li-Battery supply
Voltage measurement
Range	30-560V
Error	±0.05%
Harmonic	2^nd-51^st
Current measurement
Range (direct connection)	0.01-10A
Range (clamp CT)	5A,100A,500A,1000A,2000A (option)
Error (direct connection)	±0.05%
Error (clamp CT)	±0.2% (5A, 100A ) ±0.5% (other)
Harmonic	2^nd-51^st
Power measure error
Active power (direct connection)	±0.05%
Active power (clamp CT)	±0.2% (5A, 100A) ±0.5% (other)
Reactive power (direct connection)	±0.1%
Reactive power (clamp CT)	±0.2% (5A, 100A) ±0.5% (other)
Energy measure error
Active energy (direct connection)	±0.05%
Active energy (clamp CT)	±0.2% (5A, 100A) ±0.5% (other)
Reactive energy (direct connection)	±0.1%
Reactive energy (clamp CT)	±0.2% (5A, 100A) ±0.5% (other)
Phase angle
Range	0°-360°
Resolution	0.01°
Error	±0.05°
Frequency
Range	45Hz-65Hz
Resolution	0.001Hz
Error	0.002Hz
Pulse output
Energy constant	25000
Pulse ratio	1:1
Output level	5V
Pulse input
Input channel	2
Input level	5-10V
Input frequency	Max. 100Hz
Display
Resolution	7” TFT color (480×234)
Function
Vector diagram	Yes
Waveform	Yes
Energy accumulation	Yes
CT ratio test	Yes
Local parameter input	Yes
Wiring emulation	Yes
Self-calibration	Yes
Recorder check	Yes
Data storage	Yes
Data storage qty	5000
External extend memory	Yes
Screen printing	Yes
Communication port	USB/RS232
Communication with PC	Yes
Upload data	Yes
External mini printer	Yes
External keyboard	Yes
Mechanical parameters
Dimensions (W×H×D) (mm)	245×168×70
Weight (kg)	1.8
Environmental conditions
Ambient temperature	-25°C to +45°C
Relative humidity	30%-95%
